Enameled Wire Ferrite Core Toroidal Choke Coil For Audio Equipment

Name: Enameled Wire Ferrite Core Toroidal Choke Coil For Audio Equipment
Brand: Shinhom
Price: 1 USD

Enameled Wire Ferrite Core Toroidal Choke Coil For Audio Equipment Manufactures

Brand Name : Shinhom

Model Number : TRF142

Certification : RoHS

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T

Supply Ability : 1000000/MONTH

Delivery Time : 4~8 Weeks

Packaging Details : Carton

Wire : Enameled wire

Turns ratio : 1:1

Core : Ferrite core

Test frequency : 10kHz

Type : EMI Filter

Operating temperature : -40ºC to +125ºC

Contact Now

Ferrite core inductor , toroidal common mode choke coil , toroidal inductor for switch power supply

Common mode Choke, also known as Common mode Choke, is commonly used to filter Common mode EMI signals in switching power supplies of computers.In board card design, common-mode inductor also plays the role of EMI filter, which is used to suppress the electromagnetic wave emitted by high-speed signal line.

Components	Ferrite core, Copper wire; Plastic case
Wire	Enameled copper wire-UEW/PEW
Functions	Power line filter/Signal line filter/Energy saving/Voltage step-up etc/Choke etc
Coil Structure	Toroidal
Working Frequency Range	1KHZ-100MHZ
Inductance Range	1uH-100mH
Storage Temperature	-20℃ to +85℃
Working Temperature	-20℃ to +125℃
Test Items	Ø Turns Ratio Ø Inductance Ø DC resistance test Ø Safety test Ø Current test Ø Hi-POT
Certifications	ISO9001:2008, ISO14001:2008, UL, CQC
Package	EPE foam + export carton, or plastic tray+export carton
Feature	Low DCR common mode High current High power High efficiency Low temperature rise Stable performance
Applications	1. VCRS, Copy machine , Audio equipment , Game machines 2. TV sets, Microcomputer equipment, printers, Terminals 3. Communications control equipment 4. Switching power supply, chargers, alarm system 5. UPS, VCD/DVD players, audio and visual equipment 6. OA machines, inverters, chargers, alarm system

Enameled Wire Ferrite Core Toroidal Choke Coil For Audio Equipment

Notes: Customized is available
